14m working height Self propelled plataforma elevadora electric scissor lift work platform
Premium quality scissor lifts with accurate proportional multi-motion control, driving easier and more safety. with outstanding design,
Comparing with other similar models in the market, this model with below characteristics.
1. The proportional control system:Control the speed Of Traveling and lifting as you need.
2. Steering system. The turning radius is small,it can work In the narrow space.
3. Extension deck: You can reach the working place by the Extended platform.
Standered configuration ● Proportion control
● Charging protection
● Automatic brake
● Tilt sensor alarm
● Fault diagnosis
● Energency stop
● Emergency lowering
● Pothole protection
● Foldable guardrails
● Extendable platform
● Bio-reducible hydraulic
● Flashing beacon
● Hour meter
● Self-lock gate
● Horn
● Action buzzer
● Safety Bracket
● Trackless tire
Main Features: * The latest DTC control system with fault diagnosis system and voice guide.
* Hydraulic driving with balance valve, travel brake is more stable.
* With optional configuration of DC power drive, battery life is longer.
* Equipped with quick Charger, it is more time-saving and efficient.
* Double loading system, using efficiency of equipment is much improved.
* Centered scissor arm design, the comfort and stability of platform is improved.
* Higher working height with same numbers of scissor arms.
* Adopting electrophoresis coated, anti-corrosion performance triply improved
| Brand | SIVGE |
| Model | SZ14 |
| Platform height | 12.0 m |
| Working height | 14.0 m |
| Load capacity | 320kg |
| Table size | 2270*1140 mm |
| Machine weight | 3020 kg |
| Overall width | 1150 mm |
| Stowed size | 2480*1150*2050 mm |
| Driving mode | Self propelled |
| Lifting power | DC |
APPLICATIONS:
Business decoration, ceiling/fixture works, industrial facilities maintenance, lamps and lanterns replacement in halls, maintenance of street lamp, aerial photographs and wall cleaning etc.
PARAMETERS:
If the above specification cannot fulfill your working site, such as machine length, width and height, please contact us for further design service or non-standard models.
